How do you transport excavators within mines?

Patent Transport System

Loading and transport time is lost machine hours. Turn it around and move excavators and dozers much faster and more efficiently by using the Titan Movability Technology.

The Most Secure Way To Increase Excavators & Dozers Movability

Titan Technologies


Introduction

The Titan Range is a unique transport system with patented, remote-controlled brakes to move excavators inside mining pits and construction sites using standard on-site production equipment.

The Titan Range serves the mining industry and provides its customers with innovative, productivity-enhancing products and services.

William Wheatley (Wickham) has, with its 36 years in the mining industry, discovered the potential of the Titan Range of Equipment and has in 2021 established a Worldwide Titan Distribution and an ecommerce multi-channel sales and after-sales network.

Braking System

Safety is paramount when operating heavy machines. The Titan Range has a patented, remote-controlled, independent hydraulic brakes system that synchronizes with the brakes of the pulling vehicle. These fool-proof brakes are also used for parking and emergency stopping in case of a power failure and other emergencies.

Benefits & Features

Feature 1

Maintenance cost

The Titan exponentially increases your excavators’ mobility and utilization while reducing maintenance costs.

Feature 2

Transport Time

By using the Titan Movability, transport time may be reduced by 80%.

Feature 3

Life Time Doubled

The excavators’ undercarriage life can be more than doubled.

Titan Movability - Intro Video


Titan CET Showcases


Customer Showcase

More and more excavators are being used in production mines. When mines try to increase their production, they need to keep expanding their space

Titan CET Movability In Action

100 / 100 Tons

400 / 400 Tons

200 / 200 Tons

600 / 600 Tons

Titan CET FAQ







The Titan system Bogies are manufactured to the largest size shoe on the undercarriage of that specific mine. Any excavator on the mine with smaller shoes or narrower tracks will be able to utilise the system without modification or engineering.

Category:

Titan CET

The majority of Mining excavator manufacturers will refuse any warranty related to the tracks when the time the excavator moves on its own tracks is more than 7% of its operation time. In other words, an excavator working 24 Hours in a given day can only track or move 1.5 Hours in a day or approximately 1-2 km. With this in mind, the Titan system reduces the tracked time on the undercarriage and thus has No effect on the warranty.

Category:

Titan CET

The Titan System typically shows a weight balance between the dump truck and the Excavator of 60/40.  About 60% of the weight of the excavator lies on the Titan System and 40% on the dump truck towing the Titan System. Depending on the configuration of the dump truck and excavator, the balance between the two can differ from a ratio of 70%/30% (excavator/truck) to 50%50%. There are no additional stresses or loads on the front of the excavator or shovel.

Category:

Titan CET

On the Titan System the only maintenance required would be the periodic replacement of brake shoes, Bearings and tyre replacement when necessary. All parts are readily available from either Caterpillar or an alternative local bearing and Sintered brake supplier

Category:

Titan CET

The Titan System can utilise any of the haul trucks currently being utilised by the mine, including but not limited to Rigid Dump trucks and Articulated Dump Trucks.

Category:

Titan CET

The Titan system can be towed on any haul roads or normal mine roads where either Articulated dump trucks or Rigid dump trucks operate. No specific roads need to be graded or built for the Titan system to operate.

Category:

Titan CET

This is dependent on a few factors, including height above sea level and haul road conditions. However, depending on the mine, between 1 – 10% Gradient.

Category:

Titan CET

The Titan system allows an extremely tight turning curve due to the shorter distance between the truck and towed excavator for a minimum turning radius.

Category:

Titan CET

The Titan system has a built-in, independent hydraulic braking system for each bogie.  The hydraulic pumps control the speed of the bogies while travelling and can be activated for emergency stops.

The double depression control of the hydraulic braking system will gradually slow down the Bogeys when the excavator is being transported, at slopes and decline areas or in the case of an emergency.

Category:

Titan CET

The Titan System is completely independent and does not rely on the Excavators’ hydraulics or electrics. Once the Excavator or shovel is loaded, the umbilical cord can be disconnected and the machine moved to where it needs to be, then plugged back in to offload.

Category:

Titan CET

The Titan system is fitted with integrated battery chargers that can be kept charged via an electrical charge. There is also an option where the batteries can be kept to an optimum charge while the system is on standby via Solar Power.

Category:

Titan CET

The Titan System’s brakes are remotely controlled by either the Towing truck, the excavator being towed or the escort vehicle.  Via remote control, both machines can be brought to a safe and secure halt.

Category:

Titan CET

Other than a completely independent braking system that is not reliant on any external power source, including Air, Electrics and hydraulics, there are backup safety systems built into the Titan to ensure that the system is completely fail-proof.

Category:

Titan CET

The Titan Bogie system is made up with components and parts that are freely available and interchangeable with Caterpillar parts worldwide.

Category:

Titan CET
